Model Number |
No. of outlets |
Oil Cap. (litres) |
Total oil flow (litres/minute) |
Motor voltage |
|
|
1st stage |
2nd stage |
||||
|
SLV82 |
8 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV122 |
12 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV162 |
16 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV202 |
20 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV242 |
24 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV282 |
28 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV322 |
32 |
200 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV84 |
8 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV124 |
12 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV164 |
16 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV204 |
20 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV244 |
24 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV284 |
28 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
|
SLV324 |
32 |
400 |
19.6 |
4.8 |
380/440V-3Ph |
Note: All models are suitable for operation at 50Hz and 60Hz
MOUNTING KITS
|
Model Number |
Mounting kit type |
Applicable cylinder |
Increase in cylinder height mm |
|
SLMK-1 |
1 |
HSS - 25T |
+3.5 |
|
1 |
HSS - 30T |
+3.5 |
|
|
SLMK-2 |
2 |
HAS - 30T |
+10 |
|
2 |
HRA - 30T |
+10 |
|
|
SLMK-3 |
3 |
HSS - 50T |
+10 |
|
3 |
HAS - 50T |
+10 |
|
|
3 |
HRA - 50T; |
+10 |
|
|
SLMK-4 |
4 |
HSS - 75T |
+10 |
|
SLMK-5 |
5 |
HSS - 100T |
+10 |
|
5 |
HAS - 100T |
+10 |
|
|
5 |
HRA - 100T |
+10 |
|
|
SLMK-6 |
6 |
HDA - 25T |
+11 |
|
SLMK-7 |
7 |
HDA - 50T |
+10 |
|
SLMK-8 |
8 |
HDA - 100T |
+10 |
|
SLMK-9 |
9 |
HDA - 150T |
+10 |
|
9 |
HDA - 200T |
+10 |
|
|
SLMK-10 |
10 |
HHS - 20T |
+11 |
|
SLMK-11 |
11 |
HHS - 30T |
+12 |
|
11 |
HHR - 30T |
+12 |
|
|
SLMK-12 |
12 |
HHA - 37T |
+1 |
|
SLMK-13 |
13 |
HHA - 50T |
+1 |
|
SLMK-14 |
14 |
HHS - 60T |
+12 |
|
14 |
HHR - 60T |
+12 |
|
|
SLMK-15 |
15 |
HHS - 100T |
+10 |
|
15 |
HHR - 100T |
+10 |
|
|
SLMK-16 |
16 |
HHR - 150T |
+10 |
|
SLMK-17 |
17 |
HHR - 250T |
+10 |
|
SLMK-18 |
18 |
HFA - 30T |
0 |
|
SLMK-19 |
19 |
HFA - 50T |
+8 |
|
SLMK-20 |
20 |
HFA - 100T |
0 |
|
20 |
HGG - 150T |
0 |
|
|
SLMK-21 |
21 |
HDA - 300T |
0 |
|
SLMK-22 |
22 |
HDA - 400T |
0 |
|
22 |
HDA - 500T |
0 |
|
|
SLMK-23 |
23 |
HDA - 800T |
0 |
|
23 |
HDA - 1000T |
0 |
|
|
23 |
HFG - 800T |
0 |
|
|
SLMK-24 |
24 |
HFL - 50T |
+8 |
|
24 |
HFG - 50T |
+8 |
|
|
SLMK-25 |
25 |
HFG - 400T |
0 |
|
25 |
HFG - 500T |
0 |
|
|
25 |
HGG - 200T |
0 |
|
|
25 |
HSG - 200T |
0 |
|
|
SLMK-26 |
26 |
HFL - 100T |
+9 |
|
26 |
HFG - 100T |
+9 |
|
|
SLMK-27 |
27 |
HFL - 150T |
+8 |
|
27 |
HFG - 150T |
+8 |
|
|
27 |
HFG - 200T |
+8 |
|
|
27 |
HSG - 150T |
+8 |
|
|
SLMK-28 |
28 |
HFG - 250T |
0 |
|
28 |
HFG - 300T |
0 |
|
|
28 |
HGG - 300T |
0 |
|
|
SLMK-29 |
29 |
HSG - 300T |
0 |
|
SLMK-30 |
30 |
HFL - 250T |
+8 |
|
SLMK-31 |
31 |
HFL - 400T |
+10 |
|
SLMK-32 |
32 |
HFL - 500T |
+10 |
|
SLMK-33 |
33 |
HFG - 1000T |
0 |
DISPLACEMENT SENSORS
|
Model Number |
Type and Stroke (mm) |
|
SLDS650 |
650 |
SENSOR CABLES
|
Model Number |
Length (m) |
|
SLDC10 |
10 |
|
SLDC25 |
25 |
|
SLDC50 |
50 |
|
SLDC75 |
75 |
|
SLDC100 |
100 |
